The TS-7250 is a compact, full-featured Single Board Computer (SBC) based upon theĬirrus EP9302 ARM9 CPU. We use a TS-7200 to host our complete website and to prepare and test your Manufacturing process control, traffic management, printing system management,Ĭommunication infrastructure, website hosting, data gathering and laboratory testĮquipment. Customers are using the TS-72XX series SBC's in: energy generation, The TS-72XX rugged ARM9 SBC's have found their way into many embeddedĪpplications. The TS-ETH10 allows the addition ofĮthernet ports. Video, CAN, Com Ports, and A/D conversion. Systems' broad product line of PC/104 peripheral daughter boards. The 8/16 bit PC/104 interface enables additional functionality through Technologic Digital Signal Processing (DSP) is enabled through a standard 5 channel,ġ2bit A/D converter (Optional 8 channel, 12 bit A/D converter), 20 DIO lines and 2 To +85☌ is also standard, but CPU clock must be decreased to about 166MHz for higher Integer CPU performance is about 20% faster than our 133 Mhz x86 offerings.Įven with the standard power consumption of 2 Watts, the TS-72XX SBC's run withoutįans or heat sinks in the temperature range of -20 to +70☌. PLD provides glue logic, watchdog timer, Compact Flash IDE, and 8 bit PC/104 support. Micron SDRAM running at 66 Mhz and 8 Mb Intel Strata flash on-board. For example, on the TS-7200 model there is 32 Mb of The TS-72XX SBC's are built around and includes an on-chip 10/100 ethernet, USB, serial,Īnd Flash/SDRAM controller. The EP9302 processor from Cirrus is the highly integrated 200Mhz ARM9 processor that The TS-72XX SBC's areĪvailable in thousands of configurations, many of which are Commercial off the Shelf Power/heat makes for an extremely reliable embedded engine. Low board complexity, low component count, and low

The TS-72XX series Single Board Computers (SBC's) run on a 200 MHz ARM9 processor This manual is intended to provide the user with an overview of the board and benefits,Ĭomplete features specifications, and set up procedures.
